Place of Origin:
China
Brand Name:
Tieke
Model Number:
TK90
Video
One of the key features of Railway Hopper Wagons is the funnel plate inclination, which is set at 70° in the longitudinal direction and 90° in the transverse direction. This design ensures that the cargo is evenly distributed and allows for smooth flow during unloading. The hopper opening size is 1520*967mm, providing ample space for loading and unloading of materials.
These wagons are equipped with four bottom doors, which are used to control the discharge of the cargo. The bottom doors can be opened and closed as needed, allowing for precise and controlled unloading. The doors are designed to withstand the heavy loads and harsh conditions of railway transportation.
Railway Hopper Wagons have an axle load of 30 tons, making them suitable for carrying heavy loads. This weight capacity is essential for efficient and safe transportation of bulk materials, ensuring that the wagons can withstand the weight of the cargo without any damage.
The wagons are designed to fit standard railway gauge of 1435mm, which is the most common gauge used in railway transportation. However, the railway gauge can be customized to fit specific requirements, making these wagons suitable for various railway systems and networks.
In conclusion, Railway Hopper Wagons are an essential part of the railway transportation industry, providing a reliable and efficient means of transporting bulk materials. With their unique design and key features such as funnel plate inclination, bottom doors, and high axle load, these wagons are the preferred choice for businesses and industries that rely on railway transportation for their supply chain.
| Railway Hopper Wagons | Mineral Hopper Wagon |
|---|---|
| Max. Width | 3217mm |
| Design Speed | 80 Km/h |
| Tare Weight | 30 Tons |
| Hopper Opening Size | 1520*967mm |
| Brake System | Air Brake Comply With AAR Standard |
| Axle Load | 30 Tons |
| Loading Type | Bottom Discharge |
| Bottom Doors Qty | 4 |
| Funnel Plate Inclination | 70° longitudinal direction; 90° transverse direction |
| Pay Load | 72 Tons |
Once the hopper wagon reaches the railway station, it is loaded onto a train and transported to its destination. The bottom discharge feature of the hopper wagon ensures quick and easy unloading of the ores, further increasing the efficiency of the transportation process.
In addition to its application in the mining industry, Tieke TK90 hopper wagon can also be used for transporting other bulk materials such as coal, grains, and cement. Its versatility and reliability make it a valuable asset for any business in need of efficient and safe railway freight transportation.
The Railway Hopper Wagons are in nude packing with necessary anti-collide protection cushions. The wagons are fitted with lifting lugs to convinient for the lifting and transfer during transportation.
Our Railway Hopper Wagons are shipped via sea, rail or truck, depending on the customer's preference and location. We work with reliable transportation companies to ensure timely and secure delivery of our products.
For international orders, the wagons are shipped by sea or air freight. We comply with all necessary customs regulations and provide all required documentation for smooth and efficient delivery.
