Breif introduction:
CA-3/SA-3 Coupler is the main coupler for former Soviet Union Railways. It has higher impact speed and has significant traction effect under the extreme climate conditions.
CA-3 type automatic coupler is the main coupler for former Soviet Union railways locomotive, coaches, freight wagons. It was defined as standard coupler. CA-3 coupler can tow goods with a total weight of more than 8000 tons under bad weather conditions.
CA-3 automatic coupler belongs to non-rigid automatic coupler. It is composed of coupler body, coupler lock, lock pawl, lock stop, lock lift, lock lift shaft, bolt, nut, washer and etc. CA-3 coupler has three states: free state, coupling interlock state and uncoupling state.
CA-3 coupler has reasonable design and high structural strength. Its main parts are made of TB / T2942-E grade steel. CA-3 coupler is easy to connect and has good coupling performance. When two couplers are in free state, they can be connected once they are touched. The coupler has a unique ‘push’position, which is convenient for shunting operation. The free clearance between the connecting profiles of the two couplers is 10 mm, which belongs to the tight coupling type in structure. It has the characteristics of small coupling clearance, which can reduce the longitudinal impact of the train and improve the dynamic performance of the train.
At present, CA-3 automatic coupler is mainly used in the following countries: Armenia, Azerbaijan, Belarus, Estonia, Georgia, Kazakhstan, Kyrgyzstan, Lithuania, Latvia, Moldova, Russia, Tajikistan, Ukraine, Uzbekistan, Finland, Iraq, Turkey, Sweden, Norway, Australia, Slovakia, etc.
Main technical features:
| Name | CA-3/SA-3 GOST Standard Coupler Russian Couplers Train Car Coupler for Russia Railways |
| Application | Couplers for Russian freight cars |
| Model | CA-3 or SA-3 |
| Weight | 182.2 kg |
| Dimension | 1125x440x421mm(LxWxH) |
| Material standard | GOST 977-88 |
| Technology standard | GOST 22703-91, STO RZHD1.05.003-2006 |
| Free clearance between coupled profile | 10mm |
| Application | Passenger coach, freight wagon, locomotive |
Main dimension of CA3 coupler:
Why choose us?
Couplers ready for install:
FAQ:
Q1: Are you a trading company or a factory?
A: We are directly a factory and we manufacture and export railway wagons and wagon parts directly.
Q2: Chinese railway gauge is 1435mm, but our country’s is 1000mm gauge, will this be a problem for you?
A: Of course not, we are able to design railway wagon bogies of different gauges like 1435mm, 1000mm, 1067mm, 1520mm or other required railway gauges.
Q3: Why should I choose you, compared with your competitors?
A: Tieke Railway was transformed from wagons factory belong to Chinese Railway in 2016 and the company have over 10 years’ experiences in manufacturing railway wagons and bogies; Now as Tieke Railway is a private company and adopt modern market management strategies, our services are flexible and more considerate and our cost is more controllable.
Q4: What should I provide to get a quotation from you?
A: You could send your inquiry with detail drawings, product photos, detail technical parameters or requirement description. A complete requirement input is very important for us to provide an accurate quotation to you.
